ASTM A213 / A213M yog ib qho kev qhia tshwj xeeb rau Seamless Ferritic thiab Austenitic Alloy-Steel Boiler, Superheater, thiab Kub-Exchanger Tubes. Qhov kev qhia tshwj xeeb no suav nrog seamless ferritic thiab austenitic steel boiler, superheater, tshav kub-hloov hlab, xaiv Qib T5, TP304, thiab lwm yam.
Cov tubing qhov ntau thiab tsawg thiab tuab feem ntau muab rau qhov tshwj xeeb no yog 1/8 nyob rau hauv. [3.2mm] nyob rau hauv txoj kab uas hla mus rau 5 in. [127mm] nyob rau hauv sab nraud txoj kab uas hla thiab 0.015-0.5 nyob rau hauv. [ 0.4 mus rau 12.7mm], suav nrog, nyob rau hauv qhov tsawg kawg nkaus phab ntsa thickness los yog, yog teev nyob rau hauv kev txiav txim, nruab nrab phab ntsa thickness. Tubing muaj lwm txoj kab uas hla tuaj yeem muab tau, yog tias cov raj no ua tau raws li tag nrho lwm cov kev cai ntawm qhov kev qhia no.
Specifications ntawmStainless Hlau Tube A213
Specification:ASTM A213 rau stainless hlau raj
Qib:TP304, TP304L, TP316, TP316L, TP 310S, TP317L, TP321, TP347, TP347H thiab lwm yam.
Sab nraud txoj kab uas hla:1/8 "- 5" (3.2mm txog 127mm)
Phab ntsa thickness:{{0}} 015 in. to 0.5 in. [0.4 to 12.7 mm]
Ntev:Txheem ntev los yog raws li qhov xav tau
Nto tiav:320G, 2B, Hairline, Daim iav Polished, 400G, BA, No.1, 800G, No.3, 500G, HL, 2D, Satin, No.8, 400G, 180G, 600G, Daim iav tiav, 1D, No.4, 8K raws li xav tau
Kev Pabcuam:Decoiling, Moulding, Punching, Khoov, Txiav, Vuam
Qauv:ASTM, JIN, DIN, AISI, GB, SUS, EN
Hom kev tsim khoom:Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100 feem pua X Ray Welded
Xaus:Plain End, Beveled kawg, Threaded
Cov txheej txheem:Cold drawn, Cold dov, Kub dov Tube
Daim ntawv thov:Thaum tshav kub kub-Exchanger, Boiler, Super-Heater kev lag luam, Fais fab Generation, Khoom noj khoom haus thiab dej haus, petro-Chemical kev lag luam, thiab lwm yam.
Chemical Composition (%) ntawmStainless Hlau Tube A213
Qib | C, max | Mn, mas | P, max | S, max | Si, max | Cr | Ni | Mo | Nb | Ti |
TIAB SA 304 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 18.0-20.0 | 8.0-11.0 | - | - | - |
TP 304 H | 0.04-0.10 | 2.00 | 0.040 | 0.030 | 0.75 | 18.0-20.0 | 8.0-11.0 | - | - | - |
TP 304 L | 0.035 | 2.00 | 0.040 | 0.030 | 0.75 | 18.0-20.0 | 8.0-13.0 | - | - | - |
TP 310 S | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 24.0-26.0 | 19.0-22.0 | 0.75, max | - | - |
TP 310 HCbN | 0.04-0.10 | 2.00 | 0.030 | 0.030 | 0.75 | 24.0-26.0 | 17.0-23.0 | - | 0.20-0.60 | - |
TIAB SA 316 | 0.08 | 2.00 | 0.040 | 0.030 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | - | - |
TP 316 L | 0.035 | 2.00 | 0.040 | 0.030 | 1.00 | 16.0-18.0 | 10.0-15.0 | 2.00-3.00 | - | - |
TP 316 H | 0.04-0.10 | 2.00 | 0.040 | 0.030 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | - | - |
TP 316 Ti | 0.08 | 2.00 | 0.035 | 0.030 | 1.00 | 16.0-19.0 | 11.0-14.0 | 1.80-2.50 | - | 5C-0.70 |
TIAB SA 321 | 0.08 | 2.00 | 0.040 | 0.030 | 0.75 | 17.0-20.0 | 9.0-13.0 | - | - | 5C-0.60 |
TP 321 H | 0.04-0.10 | 2.00 | 0.040 | 0.030 | 0.75 | 17.0-20.0 | 9.0-13.0 | - | - | 4C-0.60 |
TIAB SA 347 | 0.08 | 2.00 | 0.040 | 0.030 | 0.75 | 17.0-19.0 | 9.0-13.0 | - | 10xC-1 00 | - |
TP 347 H | 0.04-0.10 | 2.00 | 0.040 | 0.030 | 0.75 | 17.0-20.0 | 9.0-13.0 | - | 8xC-100 | - |
Mechanical Properties ntawmStainless Hlau Tube A213
Qib | Kev kho cua sov | Kub F (C), min | Tensile zog ksi (MPa), min | Yield zog ksi (MPa), min | Elongation (%), min | Hardness |
Rockwell | ||||||
TIAB SA 304 | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 304 L | Kev daws | 1900 (1040) | 70 (485) | 25 (170) | 35 | 90 PAB |
TP 304 H | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 310 S | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TIAB SA 316 | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 316 L | Kev daws | 1900 (1040) | 70 (485) | 25 (170) | 35 | 90 PAB |
TP 316 H | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 316 Ti | Kev daws | 1900 (1040) | 75 (530) | 30 (205) | 10 | 90 PAB |
TIAB SA 321 | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 321 H | Kev daws | 2000 (1100) | 75 (515) | 30 (205) | 35 | 90 PAB |
TIAB SA 347 | Kev daws | 1900 (1040) | 75 (515) | 30 (205) | 35 | 90 PAB |
TP 347 H | Kev daws | 2000 (1100) | 75 (515) | 30 (205) | 35 | 90 PAB |
Rau Kub Tsim Tubes
1/2 nyob rau hauv. rau 2 1/2 nyob rau hauv. txoj kab uas hla kav, 20 feem pua, rau -12.5 feem pua
Saum toj no 2 1/2 nyob rau hauv., t/D Tsawg dua los yog sib npaug rau 5 feem pua, ntxiv rau 22.5 feem pua rau -12.5 feem pua
Saum toj no 2 1/2 nti. t/D＜5 feem pua, ntxiv rau 15 feem pua rau -12.5 feem pua
Rau Cold form tubing
Kev tso cai hloov pauv los ntawm qhov nruab nrab phab ntsa tuab yuav tsum yog ntxiv /- 10 feem pua ntawm qhov nruab nrab phab ntsa thickness rau cov hlab ntsha txias.
thiab, tshwj tsis yog tias tau teev tseg los ntawm tus neeg yuav khoom, yuav tsum ua raws li cov lus saum toj no rau cov raj kub tsim.
Ordering Information
Nws yog lub luag haujlwm ntawm tus neeg yuav khoom los qhia tag nrho cov kev xav tau uas tsim nyog rau cov khoom raws li cov lus qhia no. Xws li cov kev cai yuav tsum tau suav nrog, tab sis tsis txwv rau cov hauv qab no:
-Quantity (ko taw, meters, los yog tus naj npawb ntawm qhov ntev)
-Npe ntawm cov khoom (seamless raj)
- Qib (TP304 / L, TP316 / L, thiab lwm yam)
-Cov xwm txheej (kub tiav lossis txias tiav)
-Controlled structural yam ntxwv
-Size (sab nraum txoj kab uas hla thiab qhov tsawg kawg nkaus phab ntsa thickness, tshwj tsis yog qhov nruab nrab phab ntsa thickness yog teev)
-Length (tshwj xeeb los yog random)
-Hydrostatic Test lossis Nondestructive Electric Test
-Specification npe thiab xyoo ntawm qhov teeb meem
